• Conductor: Copper acc.to GB/T3956 CLASS 5 • Insulation: special PVC • Inner liner: PP tape or aluminum foil shield • Braiding: bare or tinned copper braid • Sheath: 70℃ PVC • Standards: JB/T8734.5 • Minimum bending radius: Flexing Installation:15×outer diameter Fixed Installation:6×outer diameter • The working temperature: Flexing Installation:-5℃—-70℃ Fixed Installation:-15℃—-70℃ • Test votage :≤0.5mm² 1500V    ＞0.5mm² 2000V • Rated votage: 300/300V

• Conducor:copper acc.GB/T3956 CLASS 5、JB/T8734 • Insulation:Speciall PVC • Inner liner:PP or non-woven for buffer • Sheath:optional • Standards:JB8734.4、 GB5023.5 • Technical data:Minimum bending diameter • Fixed Installation:15X outer diameter • Flexing Installation:6X outer diameter • Temprature range： Flexing Installation:-5℃—-70℃ Fixed Installation:-15℃—-70℃ • Test voltage:≤0.5mm² 2000V     >0.5mm² 2500V • Working voltage:≤0.5mm² 300/300V      >0.5mm² 300/500V • Optional:flat cable.

• Bare copper wire stranded conductor GB/T3956, JB/T8734 • Insulation: Polyvinyl chloride insulation • Application standards: IEC60227, GB/T5023, JB/T8734, GB/T3956 • Operating temperature range: -5℃-+70℃ • Customization: -30℃to+70℃ • Rated voltage: <0.5mm: U0/U 300/300V 0.5-1.0mm: U0/U 300/

• Conductors: Bare copper wire stranded (GB/T3956, JB/T8734) • Insulation: PVC (Polyvinyl Chloride) • Compliance Standards: IEC60227, GB/T5023, JB/T8734, GB/T3956 • Operating Temperature: -5℃ to +70℃ • Customization: -30℃ to +70℃ • Rated Voltage: – <0.5mm²: U0/U 300/300V -0.5-1.0mm²: U0/U 300/500V – ≥1.5mm²: U0/U 450/750V • Test Voltages: 1500V,2000V,2500V

• Bare copper wire stranded conductor GB/T3956, JB/T8734 • Insulation: Polyvinyl chloride insulation • Application standards: IEC60227, GB/T5023, JB/T8734, GB/T3956 • Operating temperature range: -5℃-+70℃ • Customization: -30℃to+70℃ • Rated voltage: <0.5mm: U0/U 300/300V 0.5-1.0mm: U0/U 300/
